2046 – 1982-2002 GM F-Body Rear Coil Over Kit, Double Adjustable Shocks, Bolt in
$869.99
PRODUCT DESCRIPTION
UMI's bolt-in rear coilover kit offers complete ride height, spring rate, and damping adjustability for your 1982-2002 Camaro and Firebird. The double shear upper mount is a direct bolt-in and accommodates a true 2-1/2” racing coilover. The FEA-designed lower bracket utilizes the standard shock mounting hole along with an additional reinforcement hole for installation. Drilling one 3/8” hole on each side is required, but no welding is necessary.
The Viking shock is 19-way adjustable in both compression and rebound, ensuring the ideal setting for various applications. The coilover springs come in different rates: 110lb for drag racing, 150lb for street use, and 175lb or 200lb for auto-x/road racing. This product has been tested with UMI’s 1-1/2” diameter trailing arms, 22mm sway bar, and 32mm drag anti-roll bar. Compatibility with other brand sway bars and larger diameter control arms is not guaranteed. For further fitment inquiries, please contact UMI. All components are 100% manufactured in Philipsburg, PA, USA.
The UMI rear coilover kit is tailored for racing use and may not suit every application. Occasionally, trimming or component relocation might be necessary. This kit has been confirmed to work with the UMI 22mm rear sway bar, UMI drag bar, and factory rear end, and has also been validated for compatibility with Moser Engineering and Strange brand rear ends. A set of 3/16” thick shims is included, but various aftermarket rear ends may require adjustments.
The spanner wrench tool is essential for adjusting vehicle height while the shock remains mounted, and it is needed to make height adjustments. The thrust bearing kit should be placed between the spring and the spring seat attached to the shock, facilitating easier adjustments as the spring seat rotates on a bearing. While the thrust bearing kit is recommended for smoother adjustments, it is not mandatory for installation. We do not advise adjusting height on the car without a thrust bearing kit.
PRODUCT FEATURES
- Full ride height, spring rate, and damping adjustability
- Double shear upper mount for direct bolt-in installation
- Accommodates a true 2-1/2” racing coilover
- FEA designed lower bracket with reinforcement hole
- Only one 3/8” hole per side needs to be drilled
- Viking shock with 19-way adjustable compression and rebound
- 2-1/2” coilover springs available in 110lb, 150lb, 175lb or 200lb options
- Tested with UMI trailing arms, sway bars, and drag anti-roll bar
- Made in the USA
- Brackets made from 3/16” mild steel
- Laser cut for precise fit
- Powder coated for durability
- Bolt-in design
- Includes spacers for control arm relocation brackets
- Designed, tested, manufactured, and raced in Philipsburg, PA-USA
- Application Guide:
- Drag Racing
- 110lb Spring
- Street
- 150lb Spring
- AutoX / Road Racing
- 175lb or 200lb Spring
- Key Features:
- Brackets made from 3/16” Made In USA mild steel.
- Laser cut for precise fit.
- Powder coated for durability.
- Viking double adjustable shocks with 19 compression and rebound adjustments.
- 3 spring rate options for different applications.
- 100% Bolt-in design.
- Spacers included for use with control arm relocation brackets.
- Designed, tested, manufactured, and raced in Philipsburg, PA-USA.
This Product Features
Designed & Manufactured in the USA
Durable Powder-Coat
North American Raw Materials
Precision Laser Cut Components
Precision Welds
About Viking Performance
Viking Performance, Inc. specializes in high-performance double adjustable shock absorbers and related products. Founded in 2011 by experienced racing enthusiasts, the company identified a gap in the market for affordable double adjustable shocks, allowing customers to optimize their vehicle's ride quality by independently tuning compression and rebound settings. By focusing solely on these products, Viking keeps prices competitive with single adjustable shocks, offering better performance without unnecessary costs.
Viking conducts all aspects of design, research, and manufacturing in-house, ensuring quick responses to market changes. The company has received prestigious awards like SEMA's Best Engineered Award and has expanded its product line to include various shock types, such as patented race-only Crusader shocks and lightweight aluminum struts. With a commitment to value and quality, Viking aims to provide exceptional products for racing and performance enthusiasts at accessible prices.
| Manufacturer | , |
|---|---|
| Fitment | |
| Platform | , |
| Hardware |
Included |
| Spring Rating |
110lb ,150lb ,175lb ,200lb |
| Ride Height |
-1" to +1" ,0" to -2" ,0" to +2" |
| Part Application |
Autocross/Road Race ,Drag Race ,Street |
